12V 120Ah Heated Lithium Battery

MOQ 10units
Delivery time 20-35 working days
Capacity of supply About 5 million KVAH/year
OEM/ODM Acceptable
Factory Audit Address Dongguan, China
Product Delivery Port Shenzhen, China
Delivery terms EXW, FOB, CIF

Description

Built-in self-heating system, When the environment is cold lower to -20°C, battery still can work well as charging and discharging function. ideal for industrial purposes where you need a long lifespan battery that charges quickly, or for winner uses that low temperature weather is at a premium.

This 12v 120ah heated battery  is a LiFePO4 lithium chemistry. Which offer BMS controlled safety, long life,fast-charging performance, also the BMS embeds smart balancing algorithms that control all cell voltages in the battery, making sure they are constantly at the same voltage level, optimizing battery capacity.

Built-in high accurate LiFePO4 production technology, which can extremely expend the cycle to 4000times@80%DOD.



ELECTRICAL SPECIFICATION
Nominal Voltage 12.8V
Nominal Capacity 120AH
Stored Energy 1536Wh
Resistance 45 mΩ
Self Discharge Rate <3% per Month
Maximum Continous Charge Current 120A
Maximum Continous Discharge Current 120A
Charge Cut-off Voltage 15.6 V
Discharge Cut-off Voltage 10V
Cycle life(25°C) >4000 times@80%DOD



MECHANICAL SPECIFICATIONS
Dimensions (mm) L345×W190×H250
Weight 14.7kg
Terminal Type M8
Case Material ABS
Enclosure protection IP64



TEMPERATURE SPECIFICATIONS
Discharge Temperature -20 to 55°C
Charge Temperature -20 to 55 °C
Storage Temperature -20 to 60 °C



OTHERS SPECIFICATIONS
Short Circuit Protection Automatically recover after removal of short
Life Expectancy (years) 10 years at one cycle per day



The Certification that ELB Got:
ELB Battery certification
ELB Battery certification



Check details in ELB certification center.

FEATURES

The Main features of ELB 12V 120Ah Heated Lithium Battery:



  • 12V 120Ah Lithium battery



  • Super low temperature performance(Work at -20℃)



  • 4000tims cycle life@80%DOD.



  • Super safe lithium iron phosphate (LiFePO4) chemistry reducing the risk of explosion or combustion due to high impact, over-charging or short circuit situation.



  • Battery Management System (BMS) controls the parameters of the battery to provide optimum safety by protecting against over-charging and over-discharging.



  • BMS enhanced design balances the battery cells, optimizing battery performance.



  • Delivers twice the power of lead acid batteries, even at high discharge rates, while maintaining high energy capacity.



  • Faster charging and lower self-discharge.



  • Up to 10 times more cycles than lead acid batteries.



  • Compact and only 40% of the weight of comparable lead acid batteries

Graphs - 12V

Discharge voltage Characteristic at different Rate@25°C
Discharge voltage Characteristic at different Rate@25°C



Discharge voltage Characteristic at different Temperature
Discharge voltage Characteristic at different Temperature



Charging characteristic
Charging characteristic



Capacity of LiFePO4 vs. Lead acid@Different current of discharge
Capacity of LiFePO4 vs. Lead acid@Different current of discharge



Charge voltage and SOC status @25°C
Charge voltage and SOC status @25°C



Cycle life in Different DOD @25°C
Cycle life in Different DOD @25°C

DOWNLOAD

Datasheet:

ELBH100-LFP 12V100AH LiFePO4 Battery Datasheet

Use manual:

ELBT SERIES USE MANUAL(12V)  2022

FAQs

Q1. Can I have a 12V 120Ah heated lithium battery sample order?
A. Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?
A. Sample needs 5-10 days, mass production time needs 3-5 weeks, it depends on order quantity.

Q3. Do you have any MOQ limit the 12v 120Ah heated lithium ion battery?
A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the 12v 120Ah heated lithium ion battery and how long does it take to arrive?
A. We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.

Q5. How to proceed with an 12v 120Ah heated lithium ion battery order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7. How about cycles life of your battery?
All of batteries are 4000 cycles life beyond 80% DOD. 10 years life expectancy at one cycle per day.
