PRISMATIC CELLS

ELB prismatic cells

To extremely improve battery performance,ELB adopted precise design and advanced manufacturing techniques to create perfect electric core, and launched a number of advanced electric core products that meet the requirements of different customers for high energy density, high power density, quick charging performance, long cycle, high and low temperature performance and high safety performance.

ISO18001
iso14001
iso9001
CE
UN38.3
IEC
Previous
Next

BATTERY FEATURES

  • ISO9001(Factory)
  • ISO14001(Factory)
  • ISO18001(Factory)
  • MSDS
  • UN3480(Shipping)
  • IEC 62133(Cells)
  • UL 1642(Cells)

SUPERIOR PERFORMANCE

More and more popuar all over the world due to many advantage of LiFePO4 cells.

Eco friendly Logo

Eco

Friendly

Material

Long cycle life logo

Super

Long

Cycle life

Light weight leaf logo

Super

Light

Weight

Highest safety logo

Highest

Safety

Chemistry

High energy density logo

High

Energy

Density

Fast charging logo

Fast

Charge

Avaliable

Nominal voltage

Nominal Capacity

Stored Energy

Max. Charge current

Max. Discharge current

End of Charge voltage

End of disharge voltage

Dimension

(L/W/H)

Approx. Weight

(G)

Material

Cycle life

(100%DOD)

Cycle life

(80%DOD)

Detail Datasheet

LF50(3.2V-50Ah)

3.2V

50Ah

160Wh

1C

1C

2.5V

3.65V

135*30*185mm

1380G

LiFePO4

3500

6000

Download Datasheet

LF100(3.2V-100Ah)

3.2V

100Ah

3200Wh

1C

1C

2.5V

3.65V

200*33*167mm

2380G

LiFePO4

3500

6000

Download Datasheet

LF200(3.2V-200Ah)

3.2V

200Ah

6400Wh

1C

1C

2.5V

3.65V

200*54*173mm

4100G

LiFePO4

3500

6000

Download Datasheet

LF280(3.2V-280Ah)

3.2V

280Ah

896Wh

1C

1C

2.5V

3.65V

174*72*208mm

5340G

LiFePO4

3500

6000

Download Datasheet

PERFORMANCE CHARACTERISTICS (LiFePO4 cells)

Battery Charge and discharge curve

Charge/Discharge Curve

Discharge curve at different temeprature

Discharge Curves at different temperatures(0.5C)

Disccharge curve at different rates

Discharge Curve at different rates

Prismatic cell lifespan

Cycle curves at 1C(100%DOD)

BATTERY FEATURES

  • Super safe lithium iron phosphate (LiFePO4) chemistry reducing the risk of explosion or combustion due to high impact, over-charging or short circuit situation.
  • Battery Management System (BMS) controls the parameters of the battery to provide optimum safety by protecting against over-charging and over-discharging.
  • BMS enhanced design balances the battery cells, optimizing battery performance.
  • Delivers twice the power of lead acid batteries, even at high discharge rates, while maintaining high energy capacity.
  • Faster charging and lower self-discharge.
  • Up to 10 times more cycles than lead acid batteries.
  • Compact and only 40% of the weight of comparable lead acid batteries

Need a Quotation ?Contact us now！

THE ELB BRAND PROMISE

HIGH QUALITY LOGO

QUALITY

4000 TIMES CYCLES 10 YEARS DESIGN LIFESPAN

CERTIFICATION LOGO

CERTIFICATION

ISO9001,ISO14001, OHSAS18001, CE, CB, UL, KC, FCC, BIS, IEC62133.

SERVICE LOGO

SERVICES

EXW, FOB, DAP, DDP OPTIONAL
T/T, L/C OPTIONAL
